PRODUCTS
H44W stainless steel swing check valve
H44W不銹鋼旋啟式止回閥產品用途
旋啟式止回閥適用于壓力PN1.6~16.0MPa工作溫度-29~+550°的石油、化工、制藥、化肥、電力行業等各種工況的管路上，適用介質為水、油品、蒸汽、酸性介質等
H44W不銹鋼旋啟式止回閥產品特點
旋啟式止回閥是靠管路中介質本身的流動產生的力而自動開啟和關閉的，屬于一種自動閥門。止回閥用于管路系統，其主要作用是防止介質倒流、防止泵及其驅動電機機反轉，以及容器內介質的泄放。止回閥還可用于給其中的壓力可能升至超過主系統壓力的輔助系統提供補給的管路上.旋啟式止回閥的功能是用來防止管路中的介質倒流。止回閥屬于自動閥類，啟閉件靠流動介質的力量自行開啟 或關閉。止回閥只用于介質單向流動的管路上，阻止介質回流，以防發生事故。
H44W不銹鋼旋啟式止回閥產品型號：H44W-16P、H44W-16R、H44W-16RL、H44W-25P、H44W-25R、H44W-25RL、H44W-40P、H44W-40R、H44W-40RL
H44W不銹鋼旋啟式止回閥應用規范
1. 設計、制造按API 600
2. 結構長度按ASME B16.10
3. 法蘭連接按ASME B16.5 JIS B 2212-B2214
4. 閥門檢查和試驗按API 598
